Item Description

Which is the horizon of a 2-Ways Loudspeaker?

We decided to develop something that pushes this horizon beyond imaginable. The concept of horn and 2 way was what we decided to push to the limit. We set ourselves no constraints for dimensions.

There have been several obstacles along this way and the prove that we mastered them is that the name Blumenhofer is on the Wiki.

The highlight of the loudspeaker is its absolute dynamic and finesse in the reproduction. Its complete sound stage and presentation. The feelings that it is able to deliver and evoke.

Specifications

• High efficiency
• 2-Ways loudspeaker

Cabinet

…I have ho clue how to define the woodwork of the Wiki ‘Cabinet’…
• Front midrange horn
• Back loaded bass-horn
• 25mm Birch plywood
• Resonance and flow optimized bass-horn
• External crossover
• Modular construction
• High complex structure

Components

• 2” Compression Driver with Beryllium membrane
• 38cm (16″) Paper Woofer
• Gold plated tellurium copper terminals

Features

• Bi-wiring- / Bi-amping -terminals
• Time alignment
• Flat impedance curve
• Tube Friendly
• 10 years Warranty

Technical Data

Material: Birch plywood
Thickness: 25mm / 1″
Internal Bracing: Structural bracing interaction
Frequency range: 35Hz – 20kHz ± 2dB(*)

Woofer: 380mm / 15″
Material: Paper
Bass Cabinet: Horn
Horn load: Front and back
Cross over frequency: 800 Hz

Midhigh: Compression driver
Horn Throat: 2″
Membrane dimensions: 100mm / 4″
Material: Berillium

Max power input (RMS): 150 W RMS
Efficiency: 103 dB
Impedance: 8 Ohm
Impedance linearisation: Flat impedance curve
Terminal: Bi-Amping
Material: Gold plated tellurium copper

Feet: Adjustable Spikes
Weight: 300 kg
Loudspeakers per carton: 1
Gross weight: 140 kg

(*) We think that a simple number does not reflect the actual worth and potential of this kind of speaker. The simple frequency extension cannot transmit You the emotion that this loudspeaker is able to transfer You.
