Item Description

The next step for the Corona Series is to implement in it our 20cm woofer, the one from the Tempesta 20 and widen the bass horn in the front. This version is also available with the Beryllium Mid-High Range horn, as option.

This loudspeaker preserves all qualities of its smaller brother and pushes the kick in the bass a bit more.

Specifications

• High efficiency
• 2-Ways loudspeaker

Cabinet

• Bassreflex cabinet with midrange horn
• New waveformer technology
• Front ported Bass-Reflex
• Resonance and flow optimised bass reflex
• Harmonic construction

Components

• 1.4” Compression Driver with Titan membrane
• 2x 220mm (8″) P2F Woofer
• Gold plated tellurium copper terminals

Features

• Bi-wiring- / Bi-amping -terminals
• Time aligned
• Switchable impedance linearisation for the crossover frequency
• Tube Friendly
• 10 years Warranty

Technical Data

Material: HDF-Complex
Thickness: 18mm / 0,75″
Internal Bracing: Structural bracing interaction
Frequency range: 36Hz – 20kHz ± 2dB
Bass Cabinet: Harmonic / Bass Reflex
Porting: Front, behind horn

Woofer: 2x 20cm / 8″
Material: Paper P2F® Sandwich
Cross over frequency: 850 Hz

Midhigh: Compression driver
Horn Throat: 1,4″
Membrane dimensions: 75mm / 3″
Material: Titanium

Max power input (RMS): 300 W RMS
Efficiency: 96 dB
Impedance: 4 Ohm
Impedance linearization: Yes
Terminal: Bi-Amping
Material: Gold plated tellurium copper

Feets: Adjustable Spikes
Dimensions: 450 x 630 x 1130 mm / 17.75 x 24.8 x 44.5 in
Weight: 50 kg
Packaging dimensions: 2x 70x60x103 cm & 1x 39x39x115 cm
Packaging weight: 2x 45 kg & 1x 25kg
